CB产品第二大类——电线电缆

CB产品类别 08-23 阅读：75 评论：0

在国际电线电缆产品的检测认证过程中，CB体系（IECEE CB Scheme）作为全球互认的重要桥梁，其标准规范的准确把握直接关系到产品能否顺利通关并进入目标市场。针对电线电缆类产品的检测与认证，涵盖了从聚氯乙烯绝缘电缆、橡皮绝缘电缆、中高压电力电缆到电动汽车、光伏系统及道路车辆专用电缆等多个维度的技术规范。以下是相关的电线电缆国际标准：

IEC 60227-1：额定电压450/750V及以下聚氯乙烯绝缘电缆第1部分：一般要求 / Polyvinyl chloride insulated cables of rated voltages up to and including 450/750 V — Part 1: General requirements

IEC 60227-2：额定电压450/750V及以下聚氯乙烯绝缘电缆第2部分：试验方法 / Polyvinyl chloride insulated cables of rated voltages up to and including 450/750 V — Part 2: Test methods

IEC 60227-3：额定电压450/750V及以下聚氯乙烯绝缘电缆第3部分：固定布线用无护套电缆 / Polyvinyl chloride insulated cables of rated voltages up to and including 450/750 V — Part 3: Non-sheathed cables for fixed wiring

IEC 60227-4：额定电压450/750V及以下聚氯乙烯绝缘电缆第4部分：固定布线用护套电缆 / Polyvinyl chloride insulated cables of rated voltages up to and including 450/750 V — Part 4: Sheathed cables for fixed wiring

IEC 60227-5：额定电压450/750V及以下聚氯乙烯绝缘电缆第5部分：软电缆（软线） / Polyvinyl chloride insulated cables of rated voltages up to and including 450/750 V — Part 5: Flexible cables (cords)

IEC 60227-6：额定电压450/750V及以下聚氯乙烯绝缘电缆第6部分：电梯电缆和挠性连接用电缆 / Polyvinyl chloride insulated cables of rated voltages up to and including 450/750 V — Part 6: Lift cables and cables for flexible connections

IEC 60227-7：额定电压450/750V及以下聚氯乙烯绝缘电缆第7部分：提高耐热性的多芯软电缆 / Polyvinyl chloride insulated cables of rated voltages up to and including 450/750 V — Part 7: Flexible cables screened and unscreened with two or more conductors

IEC 60245-1：额定电压450/750V及以下橡皮绝缘电缆第1部分：一般要求 / Rubber insulated cables — Rated voltages up to and including 450/750 V — Part 1: General requirements

IEC 60245-2：额定电压450/750V及以下橡皮绝缘电缆第2部分：试验方法 / Rubber insulated cables — Rated voltages up to and including 450/750 V — Part 2: Test methods

IEC 60245-3：额定电压450/750V及以下橡皮绝缘电缆第3部分：耐热硅橡胶绝缘电缆 / Rubber insulated cables — Rated voltages up to and including 450/750 V — Part 3: Heat resistant silicone rubber insulated cables

IEC 60245-4：额定电压450/750V及以下橡皮绝缘电缆第4部分：软线和软电缆 / Rubber insulated cables — Rated voltages up to and including 450/750 V — Part 4: Cords and flexible cables

IEC 60245-6：额定电压450/750V及以下橡皮绝缘电缆第6部分：电梯电缆 / Rubber insulated cables — Rated voltages up to and including 450/750 V — Part 6: Lift cables

IEC 60245-7：额定电压450/750V及以下橡皮绝缘电缆第7部分：耐热乙烯醋酸乙烯酯橡皮绝缘电缆 / Rubber insulated cables — Rated voltages up to and including 450/750 V — Part 7: Ethylene-vinyl acetate rubber insulated cables

IEC 60245-8：额定电压450/750V及以下橡皮绝缘电缆第8部分：特软线 / Rubber insulated cables — Rated voltages up to and including 450/750 V — Part 8: Cords for applications requiring high flexibility

IEC 60502-1：额定电压1kV（ $U_m = 1.2kV$ ）到30kV（ $U_m = 36kV$ ）挤包绝缘电力电缆及附件第1部分：额定电压1kV和3kV电缆 / Power cables with extruded insulation and their accessories for rated voltages from 1 kV up to 30 kV — Part 1: Cables for rated voltages of 1 kV and 3 kV

IEC 60502-2：额定电压1kV（ $U_m = 1.2kV$ ）到30kV（ $U_m = 36kV$ ）挤包绝缘电力电缆及附件第2部分：额定电压6kV到30kV电缆 / Power cables with extruded insulation and their accessories for rated voltages from 1 kV up to 30 kV — Part 2: Cables for rated voltages from 6 kV up to 30 kV

IEC 60800：额定电压300/500V及以下用于舒适加热和防结冰的加热电缆 / Heating cables with a rated voltage of 300/500 V for comfort heating and prevention of ice formation

IEC 60840：额定电压高于30kV（ $U_m = 36kV$ ）至150kV（ $U_m = 170kV$ ）挤包绝缘电力电缆及附件试验方法和要求 / Power cables with extruded insulation and their accessories for rated voltages above 30 kV ( $U_m = 36 kV$ ) up to 150 kV ( $U_m = 170 kV$ ) — Test methods and requirements

IEC 61316：盘装电缆盘 / Aparatus for safety — Cable reels for professional use

IEC 62067：额定电压高于150kV（ $U_m = 170kV$ ）至500kV（ $U_m = 550kV$ ）挤包绝缘电力电缆及附件试验方法和要求 / Power cables with extruded insulation and their accessories for rated voltages above 150 kV ( $U_m = 170 kV$ ) up to 500 kV ( $U_m = 550 kV$ ) — Test methods and requirements

IEC 62275：电气装置用电缆管理固定和保持电缆用扎带 / Cable management systems — Cable ties for electrical installations

IEC 62821-1：额定电压450/750V及以下无卤低烟聚氯乙烯绝缘电缆第1部分：一般要求 / Electric cables — Halogen-free, low smoke thermoplastic insulated and sheathed cables of rated voltages up to and including 450/750 V — Part 1: General requirements

IEC 62821-2：额定电压450/750V及以下无卤低烟聚氯乙烯绝缘电缆第2部分：试验方法 / Electric cables — Halogen-free, low smoke thermoplastic insulated and sheathed cables of rated voltages up to and including 450/750 V — Part 2: Test methods

IEC 62821-3：额定电压450/750V及以下无卤低烟聚氯乙烯绝缘电缆第3部分：固定布线用无护套电缆 / Electric cables — Halogen-free, low smoke thermoplastic insulated and sheathed cables of rated voltages up to and including 450/750 V — Part 3: Non-sheathed cables for fixed wiring

IEC 62893-1：电动汽车用额定电压最高达$1.0\text{ kV A.C.} $和$ 1.5\text{ kV D.C.}$的电缆第1部分：一般要求 / Electric cables for electric vehicles — Part 1: General requirements

IEC 62893-2：电动汽车用额定电压最高达$1.0\text{ kV A.C.} $和$ 1.5\text{ kV D.C.}$的电缆第2部分：试验方法 / Electric cables for electric vehicles — Part 2: Test methods

IEC 62893-3：电动汽车用额定电压最高达$1.0\text{ kV A.C.} $和$ 1.5\text{ kV D.C.}$的电缆第3部分：充电电缆 / Electric cables for electric vehicles — Part 3: Charging cables

IEC 62893-4-1：电动汽车用额定电压最高达$1.0\text{ kV A.C.} $和$ 1.5\text{ kV D.C.} $的电缆第4-1部分：交流充电用额定最高达$ 250\text{ A} $和$ 1.0\text{ kV A.C.}$的绞合线电缆 / Electric cables for electric vehicles — Part 4-1: Rated up to 250 A and 1 000 V A.C. or 1 500 V D.C. — Cables for charging in modes 1, 2, 3 and 4

IEC 62930：光伏系统用额定电压$1.5\text{ kV D.C.}$电缆 / Electric cables for photovoltaic systems with a voltage of 1,5 kV DC

IEC 63026：额定电压$1.5\text{ kV D.C.} $及以上至$ 3\text{ kV D.C.}$光伏系统用电缆 / Electric cables for photovoltaic systems with a rated voltage of 1,5 kV DC up to 3 kV DC

IEC 63294：风力发电用电缆技术规范 / Cables for wind power generation — Technical specification

ISO 19642-3：道路车辆 60V和600V单芯电缆第3部分：尺寸和要求（A类和B类，无屏蔽铜导体薄壁绝缘） / Road vehicles — 60 V and 600 V single-core cables — Part 3: Dimensions and requirements for unshielded copper conductor cables (classes A and B) with thin-wall insulation

ISO 19642-4：道路车辆 60V和600V单芯电缆第4部分：尺寸和要求（圆型铝导体无屏蔽绝缘） / Road vehicles — 60 V and 600 V single-core cables — Part 4: Dimensions and requirements for unshielded aluminium conductor cables

ISO 19642-5：道路车辆 60V和600V单芯电缆第5部分：尺寸和要求（圆形铜导体屏蔽绝缘） / Road vehicles — 60 V and 600 V single-core cables — Part 5: Dimensions and requirements for shielded copper conductor cables

ISO 19642-6：道路车辆 60V和600V单芯电缆第6部分：尺寸和要求（圆形铝导体屏蔽绝缘） / Road vehicles — 60 V and 600 V single-core cables — Part 6: Dimensions and requirements for shielded aluminium conductor cables

ISO 19642-7：道路车辆 60V和600V单芯电缆第7部分：尺寸和要求（扁平铜导体无屏蔽绝缘） / Road vehicles — 60 V and 600 V single-core cables — Part 7: Dimensions and requirements for unshielded copper conductor cables with flat shape

ISO 19642-8：道路车辆 60V和600V单芯电缆第8部分：尺寸和要求（扁平铝导体无屏蔽绝缘） / Road vehicles — 60 V and 600 V single-core cables — Part 8: Dimensions and requirements for unshielded aluminium conductor cables with flat shape

ISO 19642-9：道路车辆 60V和600V单芯电缆第9部分：尺寸和要求（多芯铜导体无屏蔽绝缘） / Road vehicles — 60 V and 600 V single-core cables — Part 9: Dimensions and requirements for multi-core unshielded copper conductor cables

ISO 19642-10：道路车辆 60V和600V单芯电缆第10部分：尺寸和要求（多芯铜导体屏蔽绝缘） / Road vehicles — 60 V and 600 V single-core cables — Part 10: Dimensions and requirements for multi-core shielded copper conductor cables
